Climate Controlled Growth Chamber
Alpha Smart Grow Cabinet
Model:
Alpha
Minimum Order: 01
Brief Description:
180 watt, Multi spectrum tannable light i.e adjustable spectrum and intensity control, growing area – 2’ x 2’ x4’, temperature and humidity indication, with IOT control smart grow cabinet.
Product Description
- Multi spectrum tannable light with 8 adjustable spectra.
- Multi wavelength covers- 395nm, 450nm, 520nm, 590nm, 660nm, 735nm,6500k, 2700k.
- 0-100% intensity control.
- The grow cabinet comes in at 24” wide, 24” deep and 48” high grow area,making it a great producer for the tight spaces.
- Outer dimensions 30’’ wide, 30’’ deep and 60’’ high.
- Available in Hydroponics and Soil configurations.
- Sturdy construction and locking door provide a completely safe and secure grow.
- 180-watt Multi spectrum tannable led grow light – you can adjust spectrum and intensity as per plant requirement.
- Cloud base connectivity.
- Real time data.
- Web base control.
- Temperature and Humidity Sensors.
- High PPF – 2.2 to 2.4 umol/J.
- Passive cooling .
- 4 cooling fan which helps cabinet to maintain room temperature.
- I-Ball tab fitted at top for control and indication
- Adjustable internal circulation fan for essential cross airflow distribution.
- 180 W LED Grow PANEL, with top LEDs, square design, passive cooling, more energy efficient own it, you’re ready to do research.
Applications
- Horticultural research .
- Speed Breeding.
- Pharma Companies.
Key Features
- 8 wavelength adjustment.
- 0-100% dimming provision .
- 0-1000 PPFD adjustment provision at 2.5ft from light .
- IOT control.
- High PPF – 2.4 umol/J ( Also available at 3.7 umol/J).
- Custom based design.
- Humidity and temperature indication.
Key Advantages
- Develop ‘n’ numbers of spectrum combination.
- Change intensity as per plant requirement.
- Control spectrum from remote location.
- Add wavelength as per plant requirement.
Benefits
- Suitable for all types of plant.
- Best for horticultural research and creation of spectrum recipe for any plant.
- Check performance of plant for various DLI .
- Real time data.
- Easy operation.
Technical Specifications
| Main System Technical Specification | |
| Cabinet Weight (Kg) | 75 Kg |
| Outer Dimension | |
| Height (in./mm) | 63 / 1600 |
| Width (in./mm) | 31 / 780 |
| Depth (in./mm) | 28 / 720 |
| Inner Dimension | |
| Height (in./mm) | 48 / 1210 |
| Width (in./mm) | 24 / 610 |
| Depth (in./mm) | 24 / 610 |
| Power Requirement (50Hz) | 230 VAC, 3 A single phase |
| Cooling Requirement | +15°C to +30°C |
| Temperature (Light ON) | +15°C to +45°C |
| Environmental Requirement | |
| Temperature | +15°C to +25°C |
| Humidity | Below 60% |
| Growth Envelope | Growth Bed Area (ft) | 2 X 2 | Growth Height (in./mm) | 48 / 1220 | Capacity (Liters) | 450 |
| Controller Technical Specification | |
| Control characteristic | Digital controlling |
| Control method | Web Based |
| Rated input voltage | 180VAC- 240VAC |
| Response time | ＜5sec |
| Protection function | unbalance |
| Working temperature | -25°C -- +75°C |
| Working humidity | <60% |
| Degree of protection | IP50 |
Speed Seed Grow Chamber
Model:
- Alpha
Minimum Order: 01
Brief Description:
PLC base controller, smart grow chamber, 210-watt grow light, all in one grow light,
Growing area – 60 cm x 60 cm x 90 cm (L x W x H) Temperature, Humidity and Co2
Control & indication, with AHU (air handling unit) and dimming and spectrum control of
light.
- Internal size (W x D x H) cm: 60 x 60 x 90
- Outer Size (W x D x H) in cm: 78 x 85 x 180
Grow chamber is suitable for all types of local plant growth. More energy efficient own it,
you are ready to do research.
Key Features
- All in One grow light
- 0-100% dimming of light
- 0-1000 PPFD at 45 cm from light
- 20°C to 50°C Temperature control
- 40 to 85% RH.
- 324 litter capacity of GC
- 350 to 1200 PPM Co2
- AHU with 20% fresh air per hour
Key Advantages & Benefits
- Lighting Mastery: Set ‘n’ of spectrum combination using ALL IN ONE grow light.
- Dynamic Lighting Control: Enjoy 0-100% dimming and 0-1000+ PPFD adjustments
at 50cm, tailoring light to your plants’ exact needs. - Optimal Environment: From 20°C to 50°C, fine-tune temperature and 40-85% RH
for ideal growth conditions year-round. - CO2 Supercharge: Improve photosynthesis by changing the CO2 levels (350 to 1200
PPM) for faster, healthier plants. - Fresher Air, Faster Growth: An integrated AHU introduces 20% fresh air per hour,
help to improve ventilation for promoting robust and rapid plant development. - Speed Breeding Success: Achieve exceptional results with simplified, effective
control over light, climate, and CO2 – your formula for speed breeding triumph.
Applications
- Horticultural research
- Speed Breeding
- Pharma Companies
Spectrum
Set ‘n’ number of spectrum option using ALL IN ONE grow light
Technical Details
| Main System Technical Specification | |
| Cabinet Weight (Kg) | 80 Kg |
| Outer Dimension | |
| Height (in./mm) | 70 / 180 |
| Width (in./mm) | 30 / 78 |
| Depth (in./mm) | 33 / 85 |
| Inner Dimension | |
| Height (in./mm) | 35 / 90 |
| Width (in./mm) | 24 / 60 |
| Depth (in./mm) | 24 / 60 |
| Power Requirement (50Hz) | 230 VAC, 3 A single phase |
| Cooling Requirement | 20°C to 60°C |
| Controller Technical Specification | |
| Control characteristic | Digital controlling |
| Control method | PLC control |
| Rated input voltage | 180VAC- 240VAC |
| Response time | ＜5sec |
| Working temperature | -0°C -- +45°C |
| Working humidity | <60% |
| Degree of protection | IP50 |
